Prototypes and production
Replacing the shape is not always replacing the function.
A broken component provides clues, but it may not describe the original shape or complete specification. Establish what is actually required.
/ 3D Print Direct
Identify the role before copying the outline
Explain where the part sits, what it contacts and what happens if it fails. Distinguish a cosmetic cover from a component involved in a safety-critical load, guard, electrical function or other rated application.
A print that resembles the original does not inherit its material properties, certifications or service history. Safety-critical replacements need an appropriate engineering and validation route.
Recover the geometry deliberately
Provide measurements, multiple views and the mating component where possible. A broken region may have deformed or lost material, so say which dimensions are known and which are inferred. A photograph does not define hidden geometry or scale by itself.
If no usable model exists, agree the design scope through file and model advice before assuming CAD reconstruction is included in a printing price.
Decide what may change
List fixed interfaces and any permissible non-critical changes. If the original manufacturing method differs from printing, the design may need a different preparation route. Do not silently thicken a feature or move a hole that controls assembly.
For the required fit, use clearance and tolerance planning.
Specify the use conditions
Describe handling, movement, heat, moisture, light and relevant exposure. Confirm the actual available material grade rather than identifying it only by colour or a broad plastic abbreviation. Our material guide explains that distinction.
State whether the result is a development sample or an intended replacement in use, and identify the physical checks required.
Send a replacement-aware brief
Include the model or references, measurements, mating geometry, use conditions and allowed changes. Ask through a manual enquiry where the requirement needs discussion. A functional-part brief is more appropriate than an unqualified “copy this” request.
