Design for printing

A nominal size is not a fit specification.

Two matching CAD dimensions do not tell us how an assembly should behave. Describe the fit and how it will be checked.

/ 3D Print Direct

Use the terms for different questions

Clearance is the intended gap between mating features. Tolerance describes the permitted variation around a specified dimension. A design can include a clearance and still require tolerances on the dimensions that create it.

State whether the interface should slide, locate, rotate, clip or be permanently fixed. These behaviours are not interchangeable, even when the nominal dimensions are similar.

Specify the mating component

Provide the other component’s geometry or measured drawing, with units and the relevant dimensions. Say whether it is a particular existing item or another part that will also be manufactured. Identify which faces establish alignment and which can vary.

Avoid dimensioning a hole in isolation when the fit depends on a complete stack of components.

Do not copy a universal allowance

The material, geometry and preparation affect the printed result. Prusa’s design guidance discusses iteration and fit considerations. Its printer-specific accuracy figures are not tolerances offered by 3D Print Direct.

No blanket sliding-fit gap, press-fit interference or guaranteed dimensional accuracy is supplied by this guide.

Plan a physical check

For a fit-critical development part, agree how a representative sample will be checked against the real mating component. Record the file revision and the observation before changing the design. A digital overlap check can identify a modelling issue but cannot establish the final physical fit.

If there are several interfaces, name each acceptance check rather than recording one general “fits” verdict.

Put the requirement in the enquiry

List critical dimensions, required behaviour, mating geometry, allowed changes and the intended inspection method. Specify any required tolerances explicitly so their feasibility and scope can be discussed.

Use model advice for a change to the interface. Once the revision is settled, the functional-part route explains the rest of the use brief.
