Tell us the conditions the model cannot show.
A model defines geometry, but it rarely carries the whole use specification. Send the conditions that determine whether the component can serve its purpose.
/ 3D Print Direct
Describe the job and consequence of failure
State where the component is used and what it must do. Explain relevant force directions, mounting points, repeated movement and handling. If a failure could create a safety-critical problem, identify the need for an appropriate engineering and validation route.
“Strong” is not a load case, and “functional” is not a certification.
Specify the interfaces
Include mating geometry or a dimensioned drawing. Say whether each interface should locate, slide, clip or be fixed. Mark critical dimensions and any required tolerances, together with the intended inspection method.
For an assembly, list which supplied files are references and which are parts to print. Read clearances and tolerances for the distinction between a nominal size, an intended gap and allowed variation.
Describe the environment
Include relevant heat, moisture, light, chemicals and other exposure. Confirm a particular available material grade against the requirement. A family name or a remembered colour from an original part is not enough to establish suitability.
The material guide is general education, not a list of current stock.
Identify fixed and flexible features
State what cannot move, where wall geometry may change and which faces permit support contact. Show cavities with a section. Describe whether the part must remain one piece and who will handle any assembly.
If the geometry needs revision, use model advice before pricing the intended print.
Define the acceptance check
Say whether the order is a development sample or intended for use. Specify the physical observation or measurement that matters; a digital review or photorealistic illustration does not prove the result.
Send the accepted revision, quantity, delivery postcode and required arrival date through instant quoting for accurate offered choices, or a manual enquiry for a requirement needing discussion. The functional-part service gives the broader route.
