Prototypes and production
Give one prototype one clear job.
Before sending an iteration, write the question it should answer. A prototype brief is a handoff for that specific learning step.
/ 3D Print Direct
State the question in one sentence
Try “Can this lid locate on the existing base?” or “Do these proportions feel right when handled?” rather than “Make a prototype.” These are invented prompts, not customer projects.
Separate the learning goal from the final product’s future requirements. A shape sample does not establish final-use strength, and a fit sample may not represent the eventual finish.
Define what stays fixed
Name the file revision, units and overall size. Identify the interfaces and critical dimensions needed for this iteration. If a mating component controls the check, include its geometry or a measured drawing.
List permitted changes separately: process, colour, hidden support contact or a non-critical opening may be negotiable. Do not leave the supplier to guess which compromises would invalidate the check.
Describe the observation you will make
Decide what you will record after receiving the sample: an interference location, a gap, a handling observation or feedback about proportions. State how the comparison will be made, and identify any measurements that need a defined method.
For assembly questions, read clearance and tolerance planning. For presentation decisions, explore the clearly fictional finish-priority sample.
Put the iteration into a short handoff
- Revision and files to print.
- The question this iteration should answer.
- Quantity, dimensions and reference components.
- Fixed features and permitted changes.
- The observation or acceptance check.
- Delivery destination and required arrival date.
If multiple versions are alternatives, name each one and give its own quantity. Do not call all of them “latest”.
Decide the next step after the observation
Use prototype printing for the service route. If the model needs a change, agree that scope through file advice before ordering the next revision. The development guide shows how several distinct iterations can build on one another.
