Find the file problem before changing the design.

A file that will not open, a wrongly scaled model and an incomplete solid are different problems. Start by identifying what actually changed.

/ 3D Print Direct

The file will not open

Check its actual extension, whether the export finished and whether an archive contains the model rather than a shortcut. Try opening the original export in the application that created it. If it fails there too, re-export from the saved design instead of renaming the extension.

Tell us the CAD application and export format when asking for help. A screenshot of the error is useful; passwords and unrelated private project files are not.

The file opens at the wrong size

Compare a known dimension and the overall bounding size with the design. State the intended units and provide a dimensioned reference. Do not repair a scale problem by eye or silently scale an assembly if its components have different export histories.

Once the scale is understood, repeat the export preparation checks on the corrected file.

The shape is incomplete or unexpectedly merged

Look for missing bodies, unintended duplicates and surfaces where a solid was expected. Compare the export with the source view. Automatic mesh repair can fail or alter the result; Prusa’s repair guidance provides general context.

Keep the original unchanged, save any repair as a new revision and inspect important features afterwards. “The warning disappeared” is not an acceptance check for a fit-critical part.

The geometry is valid but the requirement is unresolved

A closed model can still contain walls, cavities or interfaces that need design attention. Identify the specific feature and whether it may change. That is a design question, not necessarily a broken file.

Use file and model advice with the original file, the problem description and relevant dimensions. If you have editable CAD, the STEP handoff guide explains how to preserve a clear part selection.

Keep a useful repair record

Record the source revision, the symptom, the change and the dimensions checked afterwards. Send the corrected revision explicitly, and say whether the prior export must be ignored. This prevents an old attachment becoming the unintended printing file.
