Files and briefing

Send the right bodies in the right revision.

STEP is useful for a CAD handoff, but exporting the whole project can include more than the parts you want. Make that selection explicit.

/ 3D Print Direct

Choose the intended part or assembly

Identify the component bodies that belong in the enquiry. Exclude reference geometry and unrelated alternatives, or label them clearly as references. If a mating part is included only to explain fit, say that it is not to be printed.

Autodesk’s export documentation lists STEP as an exchange format and explains the export process. An exported file is independent of later edits to the original design, so send a new export when the revision changes.

Reopen and compare

Open the exported STEP file and check the intended bodies, overall dimensions and units against the saved design. Include a dimensioned drawing or screenshot to establish scale. Verify that separate components remain identifiable in the handoff.

A file containing surface geometry is not automatically the solid part you intended. If the receiving view differs from the source, retain both and explain the difference through model advice.

Provide the decisions CAD does not contain

State the quantity for each body, which features must remain fixed and which visible surfaces matter. Include the required fit where another component mates with the part. STEP geometry alone does not convey your acceptable tolerance, finish or production deadline.

Do not assume the instant form accepts every CAD format. Follow its current accepted files. Our manual enquiry remains the route for STEP/STP requirements outside those choices.

Keep the revision linked to the brief

Use the same revision identifier in the file name, drawing and enquiry. Explain whether an export supersedes earlier attachments or is an alternative. Avoid mixing an older assembly with newer individual components without saying so.

For a mesh export instead, read preparing a model. For the complete job context, use the quote checklist.
