Design for printing

Make size a requirement, not an assumption.

A long dimension is a reason to discuss the build route, not proof that the part needs one particular machine or must be split.

/ 3D Print Direct

Send all three dimensions

Provide the complete model with units and its maximum outside size, including projecting features. Add a dimensioned view so scale is unambiguous. Explain whether the longest feature, an internal cavity or a fixed interface controls the design.

Do not infer the available build envelope from an illustration, a fleet count or a category name. Large-format FDM is confirmed; numeric capacity is assessed against the actual job.

Explain why one piece matters

If the part cannot have a joint, describe the reason. A visible seam, a locating interface and an assembly restriction have different implications. Identify any region where a joint could be acceptable if the one-piece route is unavailable or unsuitable.

Our splitting guide is for comparing that alternative, not prescribing it.

Discuss preparation before selecting the route

Mark important faces and areas where support contact is unacceptable. Show internal spaces with a section view and explain whether openings may change. The build decision is about the complete geometry and access, not just fitting a bounding box.

For a casing or shell, use large enclosure planning to identify mounting, lid and access requirements.

Include handling and delivery

Say how the finished part will be transported, handled and used. Give the delivery postcode and required arrival date. If a sectioned delivery or later assembly is acceptable, include that in the enquiry rather than assuming it.

See UK coverage for the difference between printing, dispatch and arrival. Seven-day printing does not guarantee a completion date for a large part.

Start a model-specific discussion

Discuss a larger print with the file, dimensions and fixed requirements. Use the large-format service page for the service overview; use file advice if an alternative design needs developing.
